Wide Throw Hinge Beveled Edge Door

These type of hinge are normally used when doors are set in a reveal and are required to open 180.

Wide throw hinge beveled edge door.

For medium weight doors of low frequency. When a door is inset into a jamb or reveal that is deeper than normal you may need a swing clear hinge if the desired result would be to have the door swing open 180 degrees. The wide throw hinge sets the pivot point out away from the door allowing the door to open 180 degrees. Wide throw hinges are generally wider than they are tall which moves the hinge s pivot point outward and allows the door to swing clear of the thick jamb casing.

The wide throw hinge sets the pivot point out away from the door allowing the door to open 180 degrees depending on obstructions wide throw hinges are normally used when doors are set in a wide jamb steel base material full mortise hinges. Ssiskcon parliament door hinge wide throw expandable swing clear reversible interior exterior nrp mirror polished 32 stainless steel 4 inch x 3 inch x 5 inch with 8 self drilling screws pack of 1 2 0 out of 5 stars 1. The wide throw full mortise bearing hinge is recommended for use on standard weight medium frequency doors where it is necessary to open the door around a large reveal for beveled edge where doors are beveled on hinge side specify ta4398 or ta4798. Wide throw hinges are used when more clearance or throw is required behind the door when it is opened to 180 degrees.

Wide throw hinges are utilized where a door is recessed from the face of the frame. For beveled edge where doors are beveled on hinge side specify ta4398 or ta4798.
